Circular dies Whitworth pipe thread DIN EN ISO 228 |
|
HIGH SPEED STEEL |
HSS |
HSS |
HSS |
HSS |
||||||
EXECUTION |
Lapped thread and gun-nose |
Lapped thread and gun-nose |
Lapped thread and gun-nose |
Lapped thread and gun-nose |
||||||
MATERIAL GROUPS |
||||||||||
C = 1.75xP | C = 1.75xP | C = 1.75xP | C = 1.75xP | |||||||
LIMIT | A | A | A | A | ||||||
COATING | ||||||||||
DIN EN | 24231 | FERG | 24231 | 24231 | ||||||
Order No. EDP = Nr. + ★ | ||||||||||
DIN EN 24231 d₂ x h₁ mm |
FERG d₂ x h₁ mm |
d₁ | P h/1" |
★ | ||||||
25 x 9 |
7.62 |
G |
1/16 |
28 |
006 |
Z =4 |
Z =4 |
Z =4 |
||
30 x 11 | 38 x 10 | 9.62 | G | 1/8 | 28 | 012 | Z =5 ■ | Z =4 ■ | Z =5 | Z =5 ■ |
38 x 10 | 13.03 | G | 1/4 | 19 | 025 | Z =5 ■ | Z =5 | Z =5 ■ | ||
45 x 14 | 16.54 | G | 3/8 | 19 | 037 | Z =5 ■ | Z =5 | Z =5 ■ | ||
45 x 14 | 20.81 | G | 1/2 | 14 | 050 | Z =6 ■ | Z =6 | Z =6 ■ | ||
55 x 16 | 22.77 | G | 5/8 | 14 | 062 | Z =5 ■ | Z =5 | Z =5 | ||
55 x 16 | 26.30 | G | 3/4 | 14 | 075 | Z =6 ■ | Z =6 | Z =6 | ||
65 x 18 | 30.06 | G | 7/8 | 14 | 087 | Z =6 ■ | Z =6 | Z =6 | ||
65 x 18 | 33.07 | G 1 | 11 | 100 | Z =7 ■ | Z =7 | Z =7 | |||
75 x 20 | 37.72 | G 1 | 1/8 | 11 | 112 | Z =7 ■ | Z =7 | Z =7 | ||
75 x 20 | 37.72 | G 1 | 1/4 | 11 | 125 | Z =8 ■ | Z =8 | Z =8 | ||
90 x 22 | 41.73 | G 1 | 3/8 | 11 | 137 | Z =7 ■ | Z =7 | Z =7 | ||
90 x 22 | 44.14 | G 1 | 1/2 | 11 | 150 | Z =8 ■ | Z =8 | Z =8 | ||
90 x 22 | 47.62 | G 1 | 3/4 | 11 | 175 | Z =9 ■ | Z =9 | Z =9 | ||
105 x 22 | 59.43 | G 2 | 11 | 200 | Z =9 ■ | Z =9 | Z =9 | |||
105 x 22 | 65.53 | G 2 | 1/4 | 11 | 225 | Z =10 | Z =10 | Z =10 | ||
120 x 22 | 75.00 | G 2 | 1/2 | 11 | 250 | Z =10 | Z =10 | Z =10 | ||
120 x 22 | 81.35 | G 2 | 3/4 | 11 | 275 | Z =12 | Z =12 | Z =12 | ||
130 x 25 | 87.70 | G 3 | 11 | 300 | Z =8 | Z =8 | Z =8 | |||
■ = Stock EDP: 500 G 1/2 = 4040050000050 |
|
