Circular dies American standard straight pipe thread ANSI B1.20.1 |
 |
|
   |
 |
||||||||
HIGH SPEED STEEL |
HSS |
||||||||
EXECUTION |
Lapped thread and gun-nose |
||||||||
MATERIAL GROUPS |
 |
||||||||
 |
1.75 x P | ||||||||
| LIMIT | |||||||||
| COATING |  |
||||||||
| DIN EN | 24231 | ||||||||
| Order No. EDP = Nr. + ★ |  |
||||||||
| DIN EN 24231 d₂ x h₁ mm |
FERG d₂ x h₁ mm |
 |
d₁ | P h/1" |
★ | ||||
30 x 11 |
1/8 NPSM |
27 |
012 |
Z =5 |
|||||
| 38 x 10 | 1/4 NPSM | 18 | 025 | Z =5 ■ | |||||
| 45 x 14 | 3/8 NPSM | 18 | 037 | Z =5 ■ | |||||
| 45 x 14 | 1/2 NPSM | 14 | 050 | Z =6 ■ | |||||
| 55 x 16 | 3/4 NPSM | 14 | 075 | Z =6 ■ | |||||
| 65 x 18 | 1 | NPSM | 11.5 | 100 | Z =7 ■ | ||||
| 75 x 20 | 1 | 1/4 NPSM | 11.5 | 125 | Z =8 | ||||
| 90 x 22 | 1 | 1/2 NPSM | 11.5 | 150 | Z =8 | ||||
| 105 x 22 | 2 | NPSM | 11.5 | 200 | Z =9 | ||||
| ■ = Stock EDP:500 1/4 NPSM = 4050050000025 | |||||||||
 |
|
 |
