Circular dies ISO Metric fine thread conduit system for cable management DIN EN 60423 |
 |
|
   |
 |
|||||
HIGH SPEED STEEL |
HSS |
|||||
EXECUTION |
Lapped thread and gun-nose |
|||||
MATERIAL GROUPS |
 |
|||||
 |
C = 1.75xP | |||||
| LIMIT | 8g | |||||
| COATING |  |
|||||
| DIN EN | 22568 | |||||
| Order No. EDP = Nr. + ★ |  |
|||||
| DIN EN 22568 d₂ x h₁ mm |
FERG d₂ x h₁ mm |
 |
d₁ x P | ★ | ||
25 x 9 |
M 8 x 1-8g |
084 |
Z =4 |
|||
| 30 x 11 | M 10 x 1-8g | 104 | Z =5 | |||
| 38 x 10 | M 12 x 1.5-8g | 126 | Z =4 ■ | |||
| 45 x 14 | M 16 x 1.25-8g | 166 | Z =5 ■ | |||
| 45 x 14 | M 20 x 1.5-8g | 206 | Z =6 ■ | |||
| 55 x 16 | M 25 x 1.5-8g | 256 | Z =6 ■ | |||
| 65 x 18 | M 32 x 1.5-8g | 326 | Z =7 ■ | |||
| 75 x 20 | M 40 x 1.5-8g | 406 | Z =8 ■ | |||
| 90 x 22 | M 50 x 1.5-8g | 506 | Z =8 ■ | |||
| 105 x 22 | M 63 x 1.5-8g | 636 | Z =10 ■ | |||
| 120 x 22 | M 75 x 1.5-8g | 756 | Z =11 | |||
| ■ = Stock EDP: 500 M 20x1.5-8g = 40023500206 | ||||||
 |
|
 |
