| COMBI Drill Chamfer Tools Ø9.5-Ø12.7mm with coolant through | ||||||||||
 |
Tool Holder Order Number |
Ød Range mm | T | Ød1 | Ød3 | X | L1 | Ln | Ls | Øs |
| Y | GH-Q-O-3641 | 9.5 - 10.0 | 12 (.472”) | 9.4 (.370”) | 20.0 (.787”) | 21.3 (.839”) | 112.3 (4.421”) | 12.2 (.480”) | 48 (1.890”) | 16 (.630”) |
| GH-Q-O-3645 | 10.3 - 11.0 | 12 (.472”) | 10.0 (.394”) | 20.0 (.787”) | 21.3 (.839”) | 112.3 (4.421”) | 12.4 (.488”) | 48 (1.890”) | 16 (.630”) | |
| Z | GH-Q-O-3649 | 11.1 - 11.9 | 12 (.472”) | 10.8 (.425”) | 20.0 (.787”) | 21.3 (.839”) | 112.3 (4.421”) | 13.5 (.531”) | 48 (1.890”) | 16 (.630”) |
| GH-Q-O-3653 | 12.0 - 12.7 | 14 (.551”) | 11.8 (.465”) | 24.0 (.945”) | 24.3 (.957”) | 119.8 (4.717”) | 14.2 (.559”) | 50 (1.969”) | 20 (.787”) | |
| COMBI Series Y, Z Chamfer Drill and Chamfer Blades | ||||||||
|
 |
Blade, Carbide-TiN, 90°, front and back** Order Number (Chamfer ØD mm) |
||||||
| Ød Drill* mm inches |
Tool Holder 1 Order Number |
Drill Tip Order Number |
(0.25mm x 45°) GH-Q-M- |
(0.5mm x 45°) GH-Q-M- |
(0.75mm x 45°) GH-Q-M- |
Insert GH-H-P- |
||
| Y | 9.53 .375 | GH-Q-O-3641 | P-A-Y-0953-2A | 8 | -03723 (10.0) | -03724 (10.5) | -03725 (11.0) | -0140 |
| 10.0 .394 | GH-Q-O-3641 | P-A-Y-1000-2A | -03724 (10.5) | -03725 (11.0) | -03726 (11.5) | |||
| 10.32 13/32" | GH-Q-O-3645 | P-A-Y-1032-2A | -03725 (11.0) | -03726 (11.5) | -03727 (12.0) | |||
| 10.5 .413 | GH-Q-O-3645 | P-A-Y-1050-2A | -03725 (11.0) | -03726 (11.5) | -03727 (12.0) | |||
| Z | 11.0 .433 | GH-Q-O-3645 | P-A-Y-1100-2A | -03726 (11.5) | -03727 (12.0) | -03728 (12.5) | ||
| 11.1 7/16" | GH-Q-O-3649 | P-A-Z-1110-2A | -03726 (11.5) | -03727 (12.0) | -03728 (12.5) | |||
| 11.5 .453 | GH-Q-O-3649 | P-A-Z-1150-2A | -03727 (12.0) | -03728 (12.5) | -03729 (13.0) | |||
| 11.91 15/32" | GH-Q-O-3649 | P-A-Z-1191-2A | -03728 (12.5) | -03729 (13.0) | -03730 (13.5) | |||
| 12.0 .472 | GH-Q-O-3653 | P-A-Z-1200-2A | 12 | -03740 (12.5) | -03741 (13.0) | -03742 (13.5) | -0128 | |
| 12.5 .492 | GH-Q-O-3653 | P-A-Z-1250-2A | -03741 (13.0) | -03742 (13.5) | -03743 (14.0) | |||
| 12.7 1/2" | GH-Q-O-3653 | P-A-Z-1270-2A | -03742 (13.5) | -03743 (14.0) | -03744 (14.5) | |||
| * Non-stock standard item with extended delivery time. Spade drill 10 piece minimum. Other drill sizes available upon request. Example: Ød = 13.75mm (.541”) - P-A-O-1375-2A. ** Chamfer blades are interchangeable; maximum chamfer diameter ØD = hole Ød + 1.5mm. 1 Non-stock standard item with extended delivery time. |
||||||||
 |
Indexable Inserts for Countersinking | |||||
| Drill Ød | ØIC | L | S | Ød2 | Order Number | |
| 9.5-11.9 | 3.97 | 6.8 | 1.59 | 2.2 | GH-H-P-0140 | |
| 12.0-14.9 | 5.56 | 9.6 | 2.38 | 2.5 | GH-H-P-0128 | |
| 15.0-19.9 | 6.35 | 11.0 | 2.38 | 2.8 | GH-H-P-0130 | |
COMBI Drill/Countersink/Chamfer Tools Ø9.5-Ø17.99mm-Spare Parts |
|
Tool Holder | 1 | 2 | 3 | 4 | 7 | 8 | 9 | ||
| Set Screw | Distance Pin | Spring | Control Bolt | Torx Screw | Size | C’sink Insert | Torx Screw | Size | ||
| Y | GH-Q-O-3641 | GH-H-S-0119 | GH-Q-E-0023 | GH-H-F-0007 | GH-Q-E-0002 | GH-H-S-0070 | IP7 | GH-H-P-0131 | GH-H-S-0055 | T6 |
| GH-Q-O-3645 | GH-H-S-0119 | GH-Q-E-0023 | GH-H-F-0007 | GH-Q-E-0002 | GH-H-S-0070 | IP7 | GH-H-P-0131 | GH-H-S-0055 | T6 | |
| Z | GH-Q-O-3649 | GH-H-S-0119 | GH-Q-E-0023 | GH-H-F-0007 | GH-Q-E-0002 | GH-H-S-0071 | IP7 | GH-H-P-0131 | GH-H-S-0055 | T6 |
| GH-Q-O-3653 | GH-H-S-0119 | GH-Q-E-0024 | GH-H-F-0007 | GH-Q-E-0002 | GH-H-S-0071 | IP7 | GH-H-P-0128 | GH-H-S-0050 | T6 |
