W1035   W1733   W2853   W4090  Tapered adjustment Radial adjustment Cartridges
 W1730   W2850   W3570   W3573
  Inserts precision ground
 for fineboring tools and cartridges

Insert W 4090-…. …. L


   Part nr.
20192		 Part nr.
20193		 Part nr.
20194		 Part nr.
20460		 Part nr.
20462		 Part nr.
20464
  uncoated     coated
Code Drawing nr. R AL° P10 P40 K10 G12 G16 G26
40,900 W4090-0225 1000L 0.2 10
40,901 W4090-0425 1000L 0.4 10
40,902 W4090-0225 1620L 0.2 16
40,903 W4090-0425 1620L 0.4 16
H H
       with wiper geometry Part nr.
20198		 Part nr.
20199		 Part nr.
20200		 Part nr.
20465		 Part nr.
20467		 Part nr.
20469
  uncoated     coated
Code Drawing nr. R AL° P10 P40 K10 G12 G16 G26
40,900 W4090-0225 1011L 0.2 10
40,901 W4090-0425 1011L 0.4 10
40,902 W4090-0225 1611L 0.2 16
40,903 W4090-0425 1611L 0.4 16
H
  Part nr.
20204		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112
Code Drawing nr. R AL° PCD 10 H H
40,900 W4090-0018 0000L 0.05 0
40,901 W4090-0218 0000L 0.2 0 H H
40,902 W4090-0418 0000L 0.4 0 H H
40,903 W4090-0818 0000L 0.8 0 H H
H
       with wiper geometry Part nr.
20206		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112		 Part nr.
20112
Code Drawing nr. R AL° PCD 10 H
40,900 W4090-0018 0011L 0.05 0 H
40,901 W4090-0218 0011L 0.2 0 H
40,902 W4090-0418 0011L 0.4 0 H
   ex stock           on request
Ordering example: 1 piece W 4090-0225 1000 L G12 = Ordering number: 20460 40,900



We reserve the right to make technical changes.
